OEM Hose Reel Wall Mount / Garden Hose And Reel Set High Pressure
Product Details:
| Place of Origin: | China |
| Brand Name: | Reelworks |
| Certification: | ISO9001 |
| Model Number: | 701 Series |
Payment & Shipping Terms:
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | 1pc in carton and in Pallet |
| Delivery Time: | 40 Working Day |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 40000pcs/month |
|
Detail Information |
|||
| Product Name: | Hose Reel Wall Mount | OEM: | Yes |
|---|---|---|---|
| Hose I.D.: | 1/4" | Hose Length: | 25"7.5m |
| Working Pressure: | 300PSI 20BAR | Fitting: | 1/4" NPT 1/4" BSPT |
| Weight: | 1.98lbs/0.90kgs | Application: | Garden |
| High Light: | air water hose,water air hose |
||
Product Description
OEM Hose Reel Wall Mount / Garden Hose And Reel Set High Pressure
Hose Reel Wall Mount Introduction
Designed for compressed air applications.
Rubber/PVC blend construction offers the best of both material, lightweight than rubber air hose, more
flexible than PVC.
Anti-UV, keep the color unchanged in the sun for a long time.
TESTED TOUGH – The hose has been tested rigorously to confirm burst strength,
Anti- ozone & anti-ultraviolet, so it can reach 3 year warranty.
Double Brass 1/4" MNPT Fittings, MAX working pressure 300psi.
Hose Reel Wall Mount Feature
Extremely Flexible Easy Coiling After Use
Lightweight and easy to handle
UV Resistant
Provides 3-5 years limited warranty
Hose Reel Wall Mount Advantage
Flexibility :Easy Coiling After Use
Won’t Kink
Temperature : 176°F~-40°F / 80°C ~-40°C
Light Weight
Hose Reel Wall Mount Parameters
| Item No. USA | Item No. Europe | Hose I.D. | Hose Length | Working Pressure | Fitting | Weight | ||
| 701.004.08 | 701.010.08 | 25_ | 7.5m | 1.98lbs | 0.90kgs | |||
| 701.004.09 | 701.010.09 | 1/4" | 33_ | 10m | 300PSI | 1/4" NPT | 2.75lbs | 1.25kgs |
| 701.004.10 | 701.010.10 | 50_ | 15m | 20BAR | 1/4" BSPT | 4.07lbs | 1.85kgs | |
| 701.004.13 | 701.010.13 | 100_ | 30m | 7.92lbs | 3.60kgs | |||
| 701.008.08 | 701.012.08 | 25_ | 7.5m | 2.75lbs | 1.25kgs | |||
| 701.008.09 | 701.012.09 | 33_ | 10m |
300PSI 20BAR |
1/4" NPT 3/8" BSPT | 3.63lbs | 1.65kgs | |
| 701.008.10 | 701.012.10 | 3/8" | 50_ | 15m | 4.95lbs | 2.25kgs | ||
| 701.008.12 | 701.012.12 | 75_ | 23m | 7.70lbs | 3.50kgs | |||
| 701.008.13 | 701.012.13 | 100_ | 30m | 9.90lbs | 4.50kgs | |||
| 701.009.08 | 701.013.08 | 25_ | 7.5m | 3.96lbs | 1.80kgs | |||
| 701.009.10 | 701.013.10 | 1/2" | 50' | 15m | 300PSI | 3/8" NPT | 8.03lbs | 3.65kgs |
| 701.009.12 | 701.013.12 | 75_ | 23m | 20BAR | 1/2" BSPT | 12.10lbs | 5.50kgs | |
| 701.009.13 | 701.013.13 | 100_ | 30m | 15.62lbs | 7.10kgs | |||
