50 / 1 Wall Mounted Pneumatic Grease Pump / Air Operated Grease Pump

50 / 1 Wall Mounted Pneumatic Grease Pump / Air Operated Grease Pump

Product Details:

Place of Origin: China
Brand Name: Lubeworks
Model Number: 1701500

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: negotiation
Packaging Details: 1 piece in carton and pallet
Delivery Time: 40 working days after received your payment
Payment Terms: T/T or L/C at sight
Supply Ability: 4,000pcs per month
Get Best Price Contact Now

Detail Information

Product Name: Grease Pump Drum Application: 13kgs/30lbs
Pressure Ratio: 50:1 Oil Outlet Connection: 1/2”M
Max.fluid Pressure: 5-8bar/70-115psi Max.free Flow Rate(min): 800g/1.76lbs
High Light:

air powered grease pump

,

air operated grease pump

Product Description

50:1 Wall Mounted Pneumatic Grease Pump / Air Operated Grease Pump





Description:

  • Typical application: high pressure grease dispenser
  • 50:1 ratio allows grease to be pumped up to NLGI #2
  • For dispensing grease of all types short and long distance at high pressure
  • Non-corrosive design for long time use
  • Compatible with integrated lubrication system
  • Compatible with different sizes of grease drum in the market
  • Double action



Specifications:



Item No.

1701500

1701501

1701502

1701503

Drum application

13kgs / 30 lbs

20-30kgs / 44-66lbs

50-60kgs / 110-132lbs

180-220kgs /  400-484lbs

Pressure ratio

50:01:00

50:01:00

50:01:00

50:01:00

Air inlet pressure

5-8bar / 70-115psi

5-8bar / 70-115psi

5-8bar / 70-115psi

5-8bar / 70-115psi

Max. fluid pressure

400bar / 5600psi

400bar / 5600psi

400bar / 5600psi

400bar / 5600psi

Air motor effective diameter

63mm / 2.4"

63mm / 2.4"

63mm / 2.4"

63mm / 2.4"

Air consumption (min)

@ 8 bar 120L

@ 8bar 120L

@ 8bar 120L

@ 8 bar 120L



@ 115psi  4.3CFM

@ 115psi  4.3CFM

@ 115psi  4.3CFM

@115psi  4.3CFM

Max.free flow rate (min)

800g / 1.76lbs

800g / 1.76lbs

800g / 1.76lbs

800g / 1.76lbs

Suction tube diameter

30mm / 1.18"

30mm / 1.18"

30mm / 1.18"

30mm / 1.18"

Suction tube length

370mm / 14. 5"

480mm / 19"

740mm / 29"

940mm / 37"

Air inlet connection

1/4"quick plug

1/4"quick plug

1/4"quick plug

1/4"quick plug

1/4" NPT Female

1/4" NPT Female

1/4" NPT Female

1/4"NPT Female

Oil outlet connection

1/4" M

1/4" M

1/4" M

1/4" M

Weight

5kgs / 11lbs

5kgs / 11lbs

5.5kgs / 12lbs

6kgs / 13lbs

Package size

13x13x73cm

13x13x81cm

13x13x108cm

13x13x128cm
